Details
The Bianchi range of endurance bikes takes the cutting-edge technology used in our racing bikes and gives it a more comfortable geometry so you can put the miles in without compromising comfort.
Size | 47cm | 50cm | 53cm | 55cm | 57cm | 59cm | 61cm |
---|---|---|---|---|---|---|---|
A (mm) | 420 | 450 | 480 | 500 | 520 | 540 | 560 |
B1 (mm) | 515 | 525 | 535 | 550 | 560 | 575 | 585 |
C (mm) | 415 | 415 | 415 | 415 | 415 | 420 | 420 |
D (mm) | 68 | 68 | 68 | 68 | 68 | 68 | 68 |
E (mm) | 120 | 135 | 150 | 165 | 180 | 195 | 210 |
F (mm) | 581 | 583 | 588 | 593 | 599 | 608 | 612 |
G | 74.5° | 74.5° | 74° | 73.5° | 73.5° | 73° | 72.5° |
G1 | 70.5° | 71.5° | 71.5° | 72° | 72.5° | 72.5° | 72.5° |
H (mm) | 43 | 43 | 43 | 43 | 43 | 43 | 43 |
I (mm) | 375 | 375 | 375 | 375 | 375 | 375 | 375 |
X (mm) | 370 | 375 | 376 | 381 | 386 | 392 | 392 |
Y (mm) | 521 | 539 | 553 | 569 | 585 | 599 | 614 |
WB (mm) | 986 | 988 | 993 | 999 | 1004 | 1018 | 1023 |
Specs
Frame | Infinito CV Disc, Carbon w/Bianchi CV, Mechanical/Electronic Di2/EPS shifting compatible, 32" tire compatible, BBset PressFit 86,5x41mm, thru axle 12x142mm |
---|---|
Fork | Bianchi Full carbon w/Bianchi CV Disc, 1.5" head, flat mount, thru axle 12x100mm, compatible with 32" tire |
Rims | Vision Trimax 30 disc brake, 700X19c rims |
Tires | Pirelli P7, 700 x 28c, 60TPI, Nylon breaker, Folding |
Bottom Bracket | Shimano SM-BB72-41B |
Crankset | Shimano Ultegra FC-R8000 50x34T, Hollowtech II |
Shifters | Shimano Ultegra ST-R8020 2x11sp, hydraulic disc brake, Shimano Ultegra ST-R8025 2x11sp, smaller lever size for sizes 47/53cm |
Front Derailleur | Shimano Ultegra FD-R8000 |
Rear Derailleur | Shimano Ultegra RD-R8000 GS 11sp |
Cassette/Freewheel | Shimano Ultegra CS-R8000 11sp, 11-12-13-14-16-18-20-22-25-28-32T |
Chain | Shimano Ultegra CN-HG701-11, 11sp |
Brakes | Shimano BR-R8070 |
Rotors | Shimano SM-RT800 Center Lock, diam. 160mm |
Brake Levers | Included w/shifters |
Handlebars | Reparto Corse Compact Flat Top, alloy 2014 diam. 31,8mm, reach 80mm, drop 130mm |
Tape/Grips | Black soft Microfiber tapes w/shockproof Eva-139 |
Stem | Reparto Corse 3D Forged alloy 6061, rise +/ - 7°, height 38mm, Oversize, 1.1/8", 1 piece alloy faceplate 6061 |
Headset | FSA NO.42/47CF/ACB/5D |
Seatpost | Reparto Corse Full Carbon special dimension; special Clamp type with alloy head adjustable and reversible +/- 35mm |
Saddle | Fi'zi:k Argo Tempo R5, S alloy rail, 260x150mm |
Pedals | Sold separately |
* Subject to change without notice.
Part Numbers
Option | UPC | MPN |
---|---|---|
CK16/Turquoise / 47cm | 08032809832140 | YRB54T47IC |
CK16/Turquoise / 50cm | 08032809832171 | YRB54T50IC |
CK16/Turquoise / 53cm | 08032809832201 | YRB54T53IC |
CK16/Turquoise / 55cm | 08032809832232 | YRB54T55IC |
CK16/Turquoise / 57cm | 08032809832263 | YRB54T57IC |
CK16/Turquoise / 59cm | 08032809832294 | YRB54T59IC |
CK16/Turquoise / 61cm | 08032809832324 | YRB54T61IC |
