Norco Optic C1

Norco Optic C1
  • Color: Orange/Orange
  • Color: Orange/Orange
  • Color: Orange/Orange
  • Color: Orange/Orange
This item is currently not available.


Norco's Optic C1 is an eye-opening perspective on trail bike capability. The Optic is a fast-pedaling trail bike that rides with just the right mix of Cross Country efficiency and All-Mountain playfulness. Buff singletrack? A forest of off-camber roots? Punchy climbs and chunky descents? Yes, yes, and yes; all things are possible with dialed A.R.T. suspension powered by a Fox Factory Float DPS shock and Pike RTC fork. Roll loud and proud on fast-moving, tubeless-ready DT Swiss wheels dressed in super tacky Maxxis tires that grip through loose, high-speed berms. SRAM's Eagle XO/XX drivetrain and a carbon SRAM Eagle crank offers smooth shifting, impressive chain retention, and a wide gear range. And let's not forget the rest of the bike: an SDG Duster saddle, Ergon grips, and RaceFace handlebar and stem keep those contact points happy; SRAM Guide Ultimate disc brakes keep you in control; and a RockShox Reverb Stealth dropper post lets you get rad on all your favorite descents.


Frame Optic Carbon 110mm (29), 120mm (650B) w/carbon seatstay
Fork Rockshox Pike RCT 3 Solo Air Boost 120mm (29), 130mm (650B)
Headset FSA No 42 ACB 1.5" to 1-1/8"
Rear Shock Fox Factory Float w/Kashima DPS, EVOL
Axles Front: Boost 15 x 110mm
Rear: 12 x 148mm
Rims/Wheels DTXCM 1200 Carbon w/30mm inner
Hubs Front: DT XMC 1200 wheelset
Rear: DT XMC 1200 wheelset
Spokes DT XCM 1200 wheelset
Tires Maxxis Forecaster 2.35 3C/EXO/TR
Crankset SRAM/Truvativ Stylo Eagle carbon Boost crank
Chainrings 32T (29), 34T (650B)
Bottom Bracket SRAM GXP Pressfit BB 92
Chain SRAM PC 12 speed chain
Rear Derailleur SRAM Eagle XX 1 - 12 speed
Cassette/Rear Cogs SRAM Eagle X01 - 10-50T
Shifters SRAM Eagle XO 1 - 12 speed
Handlebars RaceFace Next R 800mmx20mm rise carbon, 35mm barbore
Tape/Grips Ergon GA 30 lock on
Stem Race Face Turbine w/CNC 50mm (29), 60mm (650B)
Brake Levers SRAM Guide Ultimate
Brakes SRAM Guide Ultimate w/180mm rotor
Saddle SDG Duster
Seat Post Rockshox Reverb Stealth w/new lever, 100mm SM, 125mm M, 150mm L/XL, 31.6mm

* Subject to change without notice.

Part Numbers

Option UPC MPN
Orange/Orange / X-Small / 27.5-inch 058817230981 650530117615
Orange/Orange / Small / 27.5-inch 058817230998 650540117615
Orange/Orange / Small / 29-inch 058817231018 650540117612
Orange/Orange / Medium / 29-inch 058817231032 650550117612
Orange/Orange / Large / 29-inch 058817231049 650560117612
Orange/Orange / X-Large / 29-inch 058817232299 650570117612
